ATLAS 8 HYBRID

ATLAS 8H - hybrid Heavy Lifter Octacopter

TECH SPECS

Dimensions (length – width – height (with gps)) – folded:

1050 x 676 x 573 [mm]

Dimensions (length (with propellers)  – width (with propellers)
– height(with gps)) – developed:

2640 x 2962 x 860 [mm]

Maximum take-off weight (MTOW):

235 [kg] (depending on configuration)

Max Weight  | Payload Capacity

100 [kg]

Endurance (at max payload):

3 to 4 Hours (Without payload)

Telemetry and video range:

100+ [km] LOS (extendable)

Degree of protection – tightness:

IP44 (upgradable to IP55)

Maximum flight altitude:

16,400 [ft]

Positioning system:

GNSS (GPS & GLONASS)

Frequency of communications:

2.4 [GHz] (AES 128 & 256 Encryption

Temperature operating range:

-20 to +60 [°C]

Possibility of automatic take-off/landing:

Yes

Number of people required:

TWO (2)

Battery features:

2X10s 1 P

Hybrid Power

8 Electric Motors + IC Engine

Navigation lights:

Yes (Green, Red and white)

Description

presense

ATLAS 8 Hybrid was conceptualized and designed to fulfill missions that require transport of heavy payloads of up to 100Kg in weight and longer endurance. This particular iteration, which is Work in Progress (WIP),  is powered by 8 electric motors and an Internal Combustion (IC) engine  utilized to provide power to the motors and recharge the batteries via a Central Control Management Unit.

Tab 2

Tab 2

Tab 2

Tab 2

Video footage

See the product in action
